Wi-Fi ZONING CONTROLLER CREATE 3 ZONES ON A TRADITIONAL TRANSFORMER

INTRODUCTION :

Zoning controller is a device to create zones that can be controlled individually by a single traditional transformer, achieving separate lighting schedules and scenarios of your existing landscape lighting systems. Only can be used with 300W and smaller low voltage landscape lighting transformer on the market today as well as retrofitted to most any existing low voltage outdoor lighting systems

FEATURES:

• Create 3 zones with Maximum 25A.
• Each zone can be used up to 25A..
• Work with 2.4GHz Wi-Fi only.
• Wi-Fi Controlled via Smart Life APP by TUYA.
• Sunset & Sunrise Function.
• FCC and IC Certified.
• Upgrade your existing landscape lighting systems to SMAR.

SKU: ET-OP120V3A-WIFI

PRODUCT PARAMETERS:

• Input: 120VAC 60Hz
• Input 1: 120VAC 60HZ
• Output 1: 120VAC 3.0A MAX
• Zoning Input: AC/DC 28V MAX
• Zoning Output Max. Current: Zone1+ Zone2 + Zone3 <25A
• Power Cord: 6-foot, heavy-gauge, grounded, water-resistant power cord with integrally molded plug
• Enclosure: Brushed 304 Stainless Steel
• Weight: 3.2lbs
• Circuit Protection: 3.5A current fuse on input

SPEC SHEET (click to download)
