Photocell

INTRODUCTION :

The photoelectric switch JL-104 is applicable to control the street lighting, passage lighting and doorway lighting automatically in accordance with the ambient lighting level.This product is designed on the basis of electrical heating structure that provides time delay over 30 seconds to avoid redundant switching against spotlight or lightning during the night time. A temperature compensator system provides consistent performance regardless of the ambient temperature. JL-104 has a gathered swivel with the sensor/switch body for convenient direction adjustment after installation,Additional swivel is also available for further adjustment.This product is certified to the Standard for Non-industrial Photoelectric Switches for Lighting Control UL773A and applicable Canadian Standards.

SKU: PC-IP120V-BK

FEATURES:

• Input: 120V 50/60Hz
• Rated Loading: 1800W, 1100VA
• On/off Level: 10-20Lx on(Dusk), 30-60Lx off (Dawn)
• Body Meas.: (L)88 x (Dia.)32mm; Stem:(Ext.)27mm, 180°
• Swivel Meas.: (L)85 x (Max Dia.)36mm, 200°
•  Lead Length: 150mm or customized
• Ambient Temperature:-40℃ ~+70℃
• Humidity:95%
• UL Certified

SPEC SHEET (click to download)
